Garbage compactor is composed of hermitical garbage box, hydraulic system and operating system, which could apply pressure to the waste to break down bulky items, to load and transport more garbage by one time. Dirty liquid flows into waste sink, perfectly preventing re-pollution. When arriving at destination, the garbage can be dumped completely. It is ideal solution for solid waste collection.
The operation system could be manual or electrical control.
Features:| Trash Compactor Truck ISUZU KV100 (6 m³ waste collection lorry) |
||
| General | Vehicle Brand | SPV |
| Chassis Brand | ISUZU | |
| Overall Dimension | 6650 * 2200 * 2680 mm | |
| GVW / Kerb Weight | 7,300 kg / 5,600 kg | |
| Cab | Cab Capacity | 3 persons allowed |
| Air Conditioner | W/ air conditioner | |
| Engine | Fuel Type | Diesel |
| Engine Brand | ISUZU engine | |
| Power | 120 Hp (88 KW) | |
| Displacement |
2999 ml |
|
| Emission Standard |
Euro IV |
|
| Chassis | Drive Type |
4X2, left hand drive |
| Transmission |
ISUZU gear box, no overhaul within 500,000km |
|
| No. of Axles |
2 |
|
| Tyre Specification |
7.00-16 |
|
| Tyre Number |
6 tyres and 1 spare tyre |
|
| Max Speed |
105 km/h |
|
| Paint |
Metallic paint |
|
| Superstructure |
Waste Box Capacity |
6 m³ |
| Waste Box Material |
Carbon steel |
|
| All other standard accessories: Tool kit, English manual…… |
||
| Optional | **Various rear loading mechanism: container lifting; hopper flip; skip loader… **Electronic operating system |
|
