ISUZU NPR Hook Lift Trash Truck for Sale

PRODUCT DETAILS

Function:
Hook lift trash truck (also called roll-off garbage truck, hook loader garbage truck, garbage collection truck, rubbish collection truck, roll on roll off truck, hook lifter truck, hook lift garbage truck, hook lift trash truck, carriage removable / dismountable garbage truck, hook loader container truck, etc. ) is designed to collect and transport municipal solid waste, widely used in residence community, hospital, municipal environmental section, garbage transportation station etc.

Hook-arm garbage trucks, also known as detachable garbage trucks, are specialized transport vehicles equipped with a hook-arm tipping mechanism. Composed of a truck chassis, a hydraulic control system, and a detachable garbage container, they are primarily used for garbage collection and transportation in municipal sanitation, property management, and industrial and mining enterprises. They utilize fully hydraulic operation to load and unload containers, supporting multiple containers per truck. They offer strong sealing and convenient dumping, effectively improving transportation efficiency.

SPV hook loaders loading capacity ranges from 1ton, 2tons, 3tons, 5tons, 8tons, 14tons, 18tons, 20 tons etc.

Features:
---- ISUZU chassis, perfect performance.

---- ISUZU engine(Japanese brand), super powerful; reliable performance, no overhaul within 100,000 km.
---- Advanced technical, high quality material, steady performance and simple operation;

---- Rational design of hook boom and locking structure make the action of hook lift much more reliable;
---- Main hydraulic components are from well-known company all over the world;
---- Safety devices: loading balance valve, double hydraulic lock valve, safety controlling valve and locking structure of container by hydraulic;
---- Rear support device is available.

Specitfication:

Hook Lift Trash Truck ISUZU (6 m³ Waste Truck)
General	Vehicle Brand	SPV
	Chassis Brand	ISUZU
	Overall Dimension	6990 * 2450 * 2700 mm
	GVW / Kerb Weight	10,550 kg / 5,070 kg
Cab	Cab Capacity	3 persons allowed
Cab	Air Conditioner	W/ air conditioner
Engine	Fuel Type	Diesel
	Engine Brand	ISUZU engine
	Power	190 HP (140 KW)
	Displacement	5391 ml
	Emission Standard	Euro IV
Chassis	Drive Type	4X2, left hand drive
	Transmission	Manual, 5-speed forward, 1 reverse
	No. of Axles	2
	Tyre Specification	235/75R17.5
	Tyre Number	6 tyres and 1 spare tyre
	Max Speed	105 km/h
	Paint	Metallic paint
Superstructure	Loading Capacity	6 CBM
	Dustbin Material	Anti-corrosive Steel
	Hydraulic System	Chinese top brand multi-way valve, cylinders
	Control Method	Manual Control, remote control as optional
	Self-discharging Incline Angle	50°
	Lifting Time	≤60S
	Unloading Time	≤60S
	The hook loader consists of underframe, linkage frame, fixed arm, telescopic arm, hook arm, locking system, hydraulic system ……..
	All other standard accessories: Tool kit, English manual……
